Product Overview

Material and Safety:
The pump housing and integrated tank are manufactured from V‑0 highest flame‑retardant grade ABS material, ensuring outstanding fire safety and long‑term durability. This meets strict international safety standards, making the SK580E ideal for hotels, hospitals, data centers, high‑rise buildings, factories, and other critical facilities.

High‑Lift & High‑Flow Performance:
The SK580E delivers a powerful 12‑meter head and a substantial 580 L/h flow rate, enabling condensate to be pumped to upper floors, over roof parapets, across long horizontal runs, or directly into building drainage systems – all from a compact tank‑type unit.

Energy Efficiency & Ultra‑Quiet Operation:
Powered by a brushless DC silent motor with soft‑start technology, the SK580E saves more than 30% of energy compared to conventional AC condensate pumps. The motor operates at exceptionally low noise levels (≤ 30 dB(A)@1m), making it suitable for noise‑sensitive environments such as offices, patient rooms, and libraries.

Intelligent Dual‑Sensor Protection:

• Built‑in water alarm with audible buzzer alerts users to potential overflow.

• Integrated check valve prevents water backflow after pump stops.

• Dual‑layer sensing – both a highly sensitive safety Pin probe capacitive sensor and a float level control sensor ensure precise liquid level detection and automatic start/stop, providing redundancy and fail‑safe operation.

• Safety switch rated 3A, normally closed, must connect to the A/C liquid level control terminal.

Integrated Tank Design:
The low‑profile, high‑capacity tank buffers condensate surges, reducing pump cycling and extending motor life. The tank‑style design allows stable, reliable operation even during periods of high condensate production.

Wide Compatibility:
Compatible with refrigeration and air conditioning equipment up to 20 HP (approx. 50 kW cooling capacity), including large air handlers, packaged AC units, condensing boilers, refrigeration racks, and industrial process cooling.

Advantages

Superior Safety – V‑0 Flame Retardant:
The V‑0 flame‑retardant ABS construction significantly reduces fire risk, providing compliance with building codes and peace of mind for facility managers and installers.

Exceptional Head & Flow for Demanding Installations:
With 12 m head and 580 L/h flow, the SK580E handles the most challenging condensate removal tasks – multi‑storey buildings, long pipe runs, and high‑humidity environments – all within a single compact unit.

Dual‑Sensor Reliability:
The combination of Pin probe capacitive sensor and float level control sensor offers redundant protection. If one sensor fails, the other ensures continued operation, minimising the risk of overflow and water damage.

Energy Savings & Silent Operation:
The brushless DC motor cuts energy consumption by over 30% compared to traditional pumps. Soft‑start and anti‑vibration features ensure near‑silent operation, improving occupant comfort in occupied spaces.

Easy Installation & Low Maintenance:
The low‑profile tank fits into confined areas, ceiling voids, and equipment cabinets. Integrated design simplifies piping connections. Accessible components allow quick cleaning and servicing without complete disassembly, reducing downtime for critical facilities.
