Product Overview

Material and Safety:
The pump housing is manufactured from V‑0 highest flame‑retardant grade ABS material, ensuring excellent fire safety and long‑term durability. This material complies with stringent international safety standards, making the SK‑CE suitable for residential, commercial, and institutional installations where space is limited and safety is critical.

Space‑Saving Corner Design:
The unique corner‑mount configuration allows the pump to be installed directly into pipe trunking elbows or tight corners, following the natural path of refrigerant and drain lines. This innovative design streamlines installation, saves valuable space, and maintains a clean, professional appearance.

Energy Efficiency & Quiet Operation:
Powered by a rare‑earth permanent magnet brushless DC motor with soft‑start technology, the SK‑CE series saves more than 30% of energy compared to conventional AC condensate pumps. The motor incorporates shockproof anti‑vibration technology for ultra‑quiet, vibration‑free operation.

Intelligent Protection Features:

• Built‑in water alarm with audible buzzer alerts users to potential overflow.

• Integrated check valve prevents water backflow after pump stops.

• High‑sensitivity Pin probe capacitive sensor ensures precise liquid level detection, enabling automatic start/stop and overflow prevention.

• Safety switch rated 3A, normally closed, must connect to the A/C liquid level control terminal for enhanced safety.

Wide Compatibility:
Compatible with refrigeration and air conditioning equipment up to 3 HP (approx. 7.5 kW cooling capacity), including split ACs, cassettes, ducted units, condensing boilers, and dehumidifiers.

Advantages

Superior Safety – V‑0 Flame Retardant:
The V‑0 flame‑retardant ABS housing significantly reduces fire risk, providing peace of mind and compliance with strict building codes – essential for hotels, schools, hospitals, and high‑rise residential buildings.

Space‑Saving Corner Installation:
The dedicated corner design fits seamlessly into pipe trunking elbows and wall corners, eliminating the need for bulky external mounts. This reduces installation time, protects the pump from accidental damage, and keeps the installation neat and unobtrusive.

Energy Savings & Silent Operation:
The brushless DC motor cuts energy consumption by over 30% compared to traditional pumps. Soft‑start and structural vibration control ensure near‑silent operation, improving occupant comfort in noise‑sensitive environments.

Reliable Automatic Condensate Removal:
The high‑precision Pin probe sensor starts the pump when condensate accumulates and stops it when drainage is complete. The overflow alarm and check valve prevent water damage, reducing maintenance calls and protecting building interiors.

Easy Maintenance:
The corner‑mount design still allows straightforward access for cleaning and servicing. The modular construction and accessible fittings simplify disassembly without removing the entire pump assembly.
