Product Overview

Material and Durability:

The pump features a compact, robust design with a durable cast iron body and a high‑quality 304 stainless steel shaft. Key water‑contact components are made of corrosion‑resistant materials, ensuring long service life even under continuous operation.

Energy Efficiency:

Equipped with a rare‑earth permanent magnet IE5 synchronous motor, the MNS‑SE‑PRO saves more than 30% of electricity compared to conventional asynchronous motors of the same power. This ultra‑high efficiency reduces energy costs and supports environmental sustainability.

Self‑Priming Function:

The pump incorporates a powerful self‑priming design with a suction lift of up to 8 meters. It easily handles long‑distance and high‑head water transfer applications, eliminating the need for manual priming or complex foot valve arrangements.

Constant Pressure & Intelligent Control:

An intelligent frequency conversion controller with a high‑precision pressure sensor delivers millisecond‑level response. The pump maintains stable outlet pressure even during simultaneous multi‑point water usage – no more pressure fluctuations or water hammer.

Quiet & Smooth Operation:

Thanks to stepless speed regulation and advanced motor technology, the MNS‑SE‑PRO operates extremely quietly (typically below 50 dB(A)). It also features wear‑resistant mechanical seals to prevent leakage and ensure reliable performance.

Advantages

High Efficiency & Energy Savings:

The IE5 permanent magnet motor cuts power consumption by over 30%, significantly lowering electricity bills and carbon footprint – an ideal choice for green building projects and cost‑conscious users.

Reliable Self‑Priming:

With a maximum suction depth of 8 meters, the pump can draw water from wells, tanks, or below‑grade sources without external priming devices. This simplifies installation and expands application possibilities.

Stable Constant Pressure:

The intelligent controller automatically adjusts pump speed to maintain constant outlet pressure regardless of flow variations. Users enjoy comfortable, steady water pressure for showers, faucets, and appliances, even when multiple outlets are open simultaneously.

Easy Installation & Maintenance:

The compact, space‑saving design allows flexible installation in tight spaces. The pump is easy to connect, and the clear digital display on the controller provides real‑time operating parameters and fault diagnostics for quick troubleshooting.

Wide Application Range:

Suitable for household water boosting, well water lifting, garden irrigation, industrial liquid transfer, cooling and air conditioning systems, as well as small commercial water supply for villas, apartments, schools, hotels, and restaurants.

Operational Conditions

The MNS‑SE‑PRO series operates reliably under the following conditions:

Liquid Temperature: Up to +40 °C (clean water, non‑aggressive liquids)

Ambient Temperature: Maximum +40 °C

pH Range: 6.5–8.5 (neutral clean water)

Maximum Suction Depth: 8 meters

Protection Class: IP54 (dust and splash water resistant)

Voltage: 220 V ±20 %, 50/60 Hz (wide voltage design)
